Metropoli’s building was conceived with two basic criteria: the creation of a place for innovation and creativity, and the commitment to bioclimatic principles. The design of the building was inspired by architectural concepts of sustainability, and incorporates advanced bioclimatic facilities and construction systems.
The objective of the experimental Ecobox was to create an innovative building that promotes the connection between man and nature.
The building takes into account the criteria of energy efficiency, renewable energies and sustainable construction methods.
The philosophy of Ecobox is in line with the overall philosophy of Metropoli: a commitment towards creativity and the construction of a sustainable future for us, our cities and our small planet.
Siemens has designed an intelligent Building Management System that monitors previous demand, external thermal conditions, and the solar energy accumulated in the water tanks located on the roof. The system is designed to make necessary adjustments to optimize comfort levels and to minimize the use of non-renewable fossil fuels.
The building is ventilated by introducing outside air that has been naturally warmed or cooled by thermal exchange below ground. During the summer, when the air in the upper part of the atrium heats up, the atrium windows open automatically. This generates a stack effect that helps maintain thermal comfort and the overall ventilation of the building.
The sun scoops placed over the atrium space integrate an automatic window opening that helps the ventilation of the building when required.
Allow light and heat to enter during the winter months, but the carefully calculated overhangs block direct sun penetration during the summer months.
Permit the level of light entering the building to be regulated according to the season and personalised for each building zone. Thus, direct sun penetration into the building can be avoided in the summer while maintaining the possibility to capture solar energy in the winter.
From the cylindrical air intakes located in the exterior, the outside air passes through the serpentine ducts located underneath the building. Here, the outside air exchanges thermal energy with the building’s main thermal storage mass whose temperature is naturally maintained at a constant 15ºC throughout the year. During the summer months, this naturally-cooled air is introduced via one set of ventilation ducts (blue system) to ‘recharge’ the thermal storage material (gravel) within the walls. Another set of ventilation ducts (green system) introduces the naturally treated air into the building spaces at a comfortable temperature all year round.
Are located underneath the building, within the walls and on the roof. The thermal storage materials (gravel and crushed stone) help to maintain optimal comfort conditions by absorbing thermal energy – heat or cold depending on the season – and releasing it slowly to the internal spaces.
The cold water produced by the vapour absorption chillers and stored in two large tanks is circulated at the roof and ceilings of the different zones of the building. The water temperature is not allowed to fall below the dew-point in order to avoid condensation. A set of ceiling fans, powered by photovoltaic energy, helps to spread the cooler air and improve the thermal comfort during the summer.
The traditional system of radiant oors using tubes buried under the oor screed ensures an even temperature distribution in the entire building. The same set of tubes that are used to warm the building in the winter is used for cooling in the summer with the cold water generated by the vapour absorption chiller. The oors and the ceilings are activated in the winter and summer respectively in order to optimize the circulation of air within the building.
All the equipment is visibly placed on the roof to create a transparent showcase of eco technology.
72 m² of the high-tech Vitosol 200 vacuum tube solar collectors are installed on the roof of the building. These solar collectors heat water that is stored in large well-insulated tanks of 6000-litre capacity. In the summer months, the vapour absorption chiller uses the latent energy from the water heated by the solar collectors to
generate cold water. Thus, the solar panels continue working throughout the year.
The modules are symbolically integrated with the façade design and also function as an additional visual filter for some interior spaces of the building.
The 24 modules of glass-glass poly-crystalline photovoltaic panels have the capacity to produce electrical energy to power diverse uses in the building.
The external areas are landscaped with multi-toned gravel chips that allow rainwater to filter through and plants that don’t require much water. The parking areas also have permeable pavements, while the retaining walls are made of crushed stone that are cast-offs from quarries.
The building reinterpreted several bioclimatic solutions of traditional architecture, especially those related to thermal inertia, building orientation, ventilation system, and cooling systems. These are integrated with the latest energy-saving technologies and the use of alternative energies.
The functional and design aspects of the building were conceived to respond to the concept of an experimental bioclimatic architecture. Each bioclimatic component is expressed clearly and honestly.
The materials selected for the building are in consonance with the bioclimatic technology used. The materials selected do not contaminate the environment and required little energy in their fabrication.
The building skin is the deliberate dialogue between the interior and exterior spaces. Openings occur only where it is necessary to introduce light or to have a visual connection with the exterior.
The main atrium is the core for interaction and exchange. The flexibility of the building allows it to accommodate from private work space to an open public dimension, hosting lectures, events, and dynamic workshops. This adaptation of space is always choreographed around this social core.
Is the central element of the building. It is the location for meetings, celebrations, communication, and interchange. It is also one of the key elements for light and energy. The essential qualities of the atrium are its scale, its space, its transparency, and the quality of light.
The building is a simple geometric form with a modular layout that permits different spatial arrangements and uses. The concept arises from the conviction that innovation occurs at the intersection of different disciplines and the confluence of distinct ideas. The common areas and the fusion spaces are the architectonic response to this criterion.
Light is a central theme of the building. The skylights over the atrium, which also function as sun scoops, allow filtered light to enter the heart of the building and to illuminate the different work spaces. The different bioclimatic elements of the façade also act as light filters and as these can be individually adjusted, they permit a wide variety of lighting conditions.
